Clearstack Bi Folding Door inner

Clearstack Bi-Folding Door

The KRGS Clearstack delivers a wall of security whilst still showcasing your product. Unlike tradition folding stack-able doors, the Clearstack sits completely inside the lease line to allow maximum shopfront space and glides smoothly along the overhead track.

Tailor made to suit the opening, the KRGS Clear Stack is available with clear infill, mesh infill, solid infill or a combination of all 3, along with no floor track equaling no trip hazard.

Enquire Now
close icon
Make an enquiry

Let us help you secure! Get your quote now with lowest price guarantee!

  • Product Information

  • Technical Specifications

  • Images

Product Information

  • Application

    Shopping Centres, Shop Fronts, Club and Hotel Bars, Counter Tops, Kiosks, Arcades, Serveries and Doorways

  • Finish

    Clear anodised is a standard, whilst Dulux powder coated range is available as an optional extra.

  • Architectural Specification

    Supply and Install Clearstack manufactured by KRGS Roller Grilles and Shutters 02 9608 9888.

  • Warranty

    A 12 month warranty against a defective materials and workmanship applies.

  • Specification

    KRGS Clearstack is available in standard width panels to provide versatility in shopfront design

  • Look

    The overall look is one of a sophisticated and elegant wall of windows whilst offering the protection of the perfect security barrier.

  • Operation

    All folding closures are manual operation. The closure is designed so that all modes of operation and locking with user standing entry.

Note: KRGS has a continuous program of development sizes or configuration of product may change at any time. For the latest in design and specification please consult with KRGS by calling us.

Technical Specifications

View / Download technical specification sheets to assist in decision-making and installation
  • Track

    Is to be constructed from sturdy extruded aluminium, 40mm wide by 40mm high (to the centre of the track). The track has a unique joining pin system to ensure smooth operation of the closure.

  • Curtain

    The curtain is constructed of low friction continuous hinged panels, these are interlocked and secured on to the locking posts at each end, and sections are then joined via a unique intermediate post system bottom only locking to secure it. The panels are in filled with a choice of clear infill, perforated vision mesh , solid infill or a combination of all 3. The Clearstack sits completly inside the lease line to allow maximum shopfront space and glides smoothly along the overhead track. Tailor made to suit the opening.

Locking

Locking is via a key system which throws a stell rod into the dust proof floor socket, which is drilled into the floor. Key operation is from both inside and out, multiple doors can also be keyed alike.

Weight and Stacking

Door weights are approximately 45kg/1m. Always contact KRGS Technician for accurate stacking details.

diagram

Are you not sure which door is the best application for your project? KRGS’ White Paper will be able to assist in guiding you as to what door is best to meet your needs. A door design with you in mind, there is a KRGS product option to suit most of your requirements.
